The sprayer features an electrostatic operating system ensuring comprehensive spraying coverage across every inch of the trees. Enhanced by an agitation tank, high-pressure pump, and a double-sized fan with adjustable angle blades, productivity is maximized. With a spraying capacity reaching up to 12 meters, the stainless steel tank boasts a 1000-liter capacity and a two-speed adjustable turbo fan, all meticulously crafted to ensure lasting efficiency. Offering versatility, there are two trailer sprayer models with varying fan sizes, nozzle numbers, and spraying capacities, along with a smaller model designed for tractor mounting. Operating the trailer sprayer is a breeze, facilitated by the available PTO shaft for seamless connection to the tractor's three-point linkage.
Product Highlight
- Specially designed trailer sprayer with superior features
- Premium material and assured workmanship
- Variety of choices
Usage
- Fruit Orchards
Model : AS-600EM-75
Tractor HP : Min. 40 HP
Power Take-Off : PTO Shaft
Recommended PTO RPM : Min. 540 RPM
Tank Capacity : 600 L
Material - Tank / Fan Cover/ Cover : Stainless Steel
Pump Type : Diaphragm Pump
Engine Oil : 2.5 Litre
Pump Capacity : 14 litre/minute
Maximum Pressure : 50 bar
No. of Nozzles : RH 5 heads /LH 5 heads (Adjustable)
Fan Diameter : 75 cm
Electric : Battery 12V
Control Valve : Electric Solinoid, Manual Valve
Tank Mixer : Auto Mix
Measurement : 70x120x100 cm
Net Weight : 300 kg
Gross Weight incl. chemical : 900 kg
Maximum Spraying : 12-15 M
Spray Hoses by hand on both sides : No Hoses
Model : AS-1000ET-85
Tractor HP : 45 HP
Power Take-Off : PTO Shaft
Recommended PTO RPM : Min. 540 RPM
Tank Capacity : 1000 L
Material - Tank / Fan Cover/ Cover : Stainless Steel
Pump Type : Diaphragm Pump
Engine Oil : 2.5 Litre
Pump Capacity : 14 litre/minute
Maximum Pressure : 50 bar
No. of Nozzles : RH 8 heads /LH 8 heads (Adjustable)
Fan Diameter : 85 cm
Electric : Battery 12V
Control Valve : Electric Solinoid, Manual Valve
Tank Mixer : Auto Mix
Measurement : 160 x 320 x 170 cm
Net Weight : 500 kg
Gross Weight incl. chemical : 1500 kg
Maximum Spraying : 12 M
Spray Hoses by hand on both sides : Hoses 50 M Lenght
